Lithofacies Types、Vertical Profile Features and Reservoir Geological Models of Braided Deltaic Sandbodies in Faulted Lake Basin──The Observation on Deposition of Modern Deltas in Daihai Lake, Inner Mongolia
-
摘要: 粗粒三角洲是陆相湖盆的主要充填实体,然而,在中国东部陆相湖泊断陷盆地或裂谷型盆地中,由于盆地短轴方面断层陡缓程度的差异所造成的不对称性断陷盆地,使得其沉积充填实体之一的三角洲也因此而出现其各自的特色和差异。为此,本文通过岱海湖短轴方向陡、缓两侧辫状河三角洲沉积特征的比较来阐明各自的储层地质特点及与扇三角洲的区别,进而分析不同背景下辫状河三角洲的沉积特点、储层沉积学规律和砂体骨架在三维空间展布的地质模型。Abstract: Daihai lake is located in central inner Mongolia and is a modern faulted basin of terrestrial factes.This modern basin is well comparative with the faulted basin of Meozoic and Cenozoic era in the eastern part of China.Deltas is often important infilling sandbodies in faulted basin of terrestrial factes.Therefore, this peper is mainly emphasized on the analysis and Study on the depeitional processes and the favorable reservior sandbodies on different sedimentary scales of two delays in the direction of short axis in Daihai lake basin.One delta, called Yuanzigou delay, is located in thenorthern steep slope of the lake basin, while another one, Bulianghe detla, in the sourthen gentle slope of the lake basin.Both are fluvial-dominated braided deltuic system with coarse deceits.Provenances of two delays are varying form eath other.Yuanzigou river is a short distance ephemeral braided stream and Bulianghe river a long distance ephemeral braided stream.Through element analysis of lithology, grain size, sedimentary structures, thickness of sandbeds, clastic components and color etc., the description and interpretation of the depositional features of two delays are provided.12 lithofacies or genetic factes form two delays have been defined.Their mutual assemblages in verprofile make up different type of lithofaices assemblages or vertical sedimentary sequences, each corresponding to a cerium depeitional process and subenvironment.Therefore, nine sedimentury sequences have been recognized which reflect depositztional features in different perts of two btaided delays.The four sedimentary sub environments or sedimentary factes zones of each delay were distinguished by depeitional features,that is, (1) upper delta plain, (2) lower delta plain, (3) delta front slope and (4) pre-delta.The two delay have been modelled.There are both similarities and differences of depositional features among Yuanzigen delta and Bulianghe delay.Moreever depositional precesses and features between fan delta and braided delta have been discussed in this paper.There exists apparent control of depeitional processes and sedimentary factes zones on the reservoir of two delays.The deltas of the steep and gentle slope in the direction of short axis in the faulted barn have some different features of sedimentary and geometry shape of sandbodies.Finally,through sedimentary sequences, porosity zones and sandbodies geometry of two delays, the sketch model of two delays,sandbody at 3-D sauce extension in each sedimentary zones have been set up.
-
[1] 1.李华章,1972,岱海的形成及地貌发育特征,北京师范大学学报(自然科学版).(1)。
2.于兴河等,1992,华北地区二叠系岩相组合类型、剖面特点及沉积体系.沉积学报,( 1) :27---350
3.裘亦楠等,1992,定量储层沉积学一一建立储层地质模型的基础,石油勘探开发研究院内部资料。
4.陈继新等,1992,国外储层建模技术,中国石油天然气总公司情报研究所出版。
5.A.T.Buller and E.Berg et al.,1989,North Sea oil and gas reservoir一H by the Norwegian institute of Technology.
6.G.J.Orton, 1988,A spectrum of Middle Ordovician fan deltas and braid plain delats.North Wales;a consequence of varyingfluvial clastie input, Fan deltas;Sedimentology and Tectonic Settings.Eds.W.Nemec and R.J.Steel., 23一99.
7.John.G.Mcpherson, et al.,1988, Fan deltas and braid deltas; conceptual problems.Fan Deltas; Sedimentology andTectonic Settings.Eds, W.Nemec and R.J.Steel, 19一22.
8.Mall.A.D.,1978, Lithofacies types and vertical profile models in braided river.Fluvial Sedimentology, 597一609.
