陆相坳陷盆地烃源岩内致密砂岩储层含油性主控因素——以松辽盆地北部中央坳陷区齐家凹陷高台子油层为例
- 大庆油田有限责任公司勘探开发研究院 黑龙江大庆 163712
基金项目:
国家科技重大专项(2011ZX05001-001);中国石油天然气股份公司重大科技专项(2012E2603-01)
作者简介:
张金友,男,1983年出生,工程师,石油成藏综合研究、井位部署及储量评价,E-mail:zhangjinyou@petrochina.com.cn
- 收稿日期:
2015-10-15
- 修回日期:
2016-01-25
- 刊出日期:
2016-10-10
摘要: 松辽盆地北部中央坳陷区齐家凹陷青山口组高台子油层是典型的烃源岩内致密砂岩油。通过对储层宏观、微观含油性分析及含油性主控因素的深入研究,表明高台子油层储层含油性主要受沉积微相、成岩作用及烃源岩质量的综合控制,表现为有利沉积微相控制储层含油富集程度,河口坝、远砂坝微相砂体内大喉道发育,物性好,为致密油运移提供优势通道,同时储集空间相对发育,为致密油提供更广泛的聚集场所,油气最富集,沉积微相是控制高台子油层“甜点区”发育的关键地质条件。成岩作用控制石油差异分布,机械压实和胶结作用导致储层在油气大规模运聚之前普遍进入致密化,局部胶结作用弱的砂岩及溶蚀作用强烈的砂岩,大孔隙及大喉道发育,后期石油充注储层发生差异聚集,砂岩呈现不同的含油级别。烃源岩质量控制储层含油的普遍程度,好-最好烃源岩区油源充足、充注动力强,且就近运聚,虽然砂体薄,物性差,但砂体含油更普遍,含油物性下限低,差-中等烃源岩区砂体厚度大,物性总体较好,但受烃源岩质量及沉积、成岩作用综合控制,砂体含油普遍性差,主要以砂体中部物性好的层段含油为主,干砂层增多。甜点区主要分布在成熟烃源岩内部,纵向多套含油层系错叠形成甜点区连片分布,中北部含油砂体累计厚度大,物性好,向南部变差,计算甜点区资源1.5×108 t,勘探前景良好。
Main Controlling Factors of Oilliness Property of Tight Sandstone Reservoir within Source Rock in Continental Depression Basin: A case of Gaotaizi oil reservoir in Qijia sag of central depression area in northern Songliao Basin
- Research Institute Petroleum Exploration & Development of Daqing Oilfield Co., Ltd., Daqing, Heilongjiang 163712, China
Funds:
National Sciences and Technology Major Projects, No. 2011ZX05001-001; China National Petroleum Corporation Major Science and Technology Projects, No. 2012E2603-01
- Received Date:
2015-10-15
- Rev Recd Date:
2016-01-25
- Publish Date:
2016-10-10
Abstract: Typical tight sandstone oil within hydrocarbon source rocks is considered in Gaotaizi oil-layer of Qingshankou Formation in Qijia Sag, located in central depression area of northern Songliao Basin. Macro- and micro-analysis of oil-bearing property and in-depth study of the main controlling factors have been carried out in reservoir, which show that oil-bearing property of the reservoir of Gaotaizi oil-layer is mainly controlled by sedimentary micro-facies, diagenesis and quality of source rock. Favorable sedimentary microfacies controls oil enrichment in reservoir. Macro pore throats are developed in sandbodies of mouth bars and distal sandbars, where the physical properties are good enough to provide preferential pathways for migration and meanwhile relatively developed storage space can also provide more entrapment habitats. The sedimentary micro-facies is the critical geological factor controlling the distribution of "sweet spots" within Gaotaizi oil-layer. Diagenesis controls the differential distribution of hydrocarbon, and mechanical compaction and cementation led to tightness of reservoir before the large-scale migration-accumulation. While in local sandstones with weak cementation and heavy corrosion developed macro pores and throats. In the later charging process differential entrapment took place in the reservoir sandstones, having different levels of shows. Source rock quality controls the level of oil occurrence within reservoir. Good-excellent quality source rock can provide abundant hydrocarbon and powerful charging dynamics. And, therefore the hydrocarbon can be migrated to and accumulated in reservoir within the source rocks. So, the shows are common even though the sand bodies may be thin and with bad physical properties, showing that the low-limits of physical properties are relatively low. While in bad-middle quality source rock area the sand bodies are thick with better physical properties, but the oil-bearing property is controlled by the combination of source rock quality, sedimentation and diagenesis. So the shows are commonly bad, only the middle part with good physical properties of sand bodies bear oil and more dry sand bodies are discovered, too. "Sweet spot" zones are principally distributed in the mature source rock area where multiple series of oil-layers are staggered and overlapped. A conclusion can be drawn that in the mid-north oil-bearing sand bodies are of thick cumulative thickness and good physical properties, but to the south they get worse. In all the "sweet spot" zones 1.5×108t of resources can be estimated, which offers exciting exploration prospect.
张金友. 陆相坳陷盆地烃源岩内致密砂岩储层含油性主控因素——以松辽盆地北部中央坳陷区齐家凹陷高台子油层为例[J]. 沉积学报, 2016, 34(5): 991-1002. doi: 10.14027/j.cnki.cjxb.2016.05.018
ZHANG JinYou. Main Controlling Factors of Oilliness Property of Tight Sandstone Reservoir within Source Rock in Continental Depression Basin: A case of Gaotaizi oil reservoir in Qijia sag of central depression area in northern Songliao Basin[J]. Acta Sedimentologica Sinica, 2016, 34(5): 991-1002. doi: 10.14027/j.cnki.cjxb.2016.05.018
Citation: |
ZHANG JinYou. Main Controlling Factors of Oilliness Property of Tight Sandstone Reservoir within Source Rock in Continental Depression Basin: A case of Gaotaizi oil reservoir in Qijia sag of central depression area in northern Songliao Basin[J]. Acta Sedimentologica Sinica, 2016, 34(5): 991-1002. doi: 10.14027/j.cnki.cjxb.2016.05.018
|
